Waters RXN 1000 Reaction Coil Assembly for HPLC

The Waters RXN 1000 reaction coil is designed for liquid chromatography applications where on-line chemical modification or derivatization of analytes is required. The RXN 1000 coil has several unique features which make it ideal for post-column reaction systems, such as an inert fluid path compatible with most solvents and reagents (even at elevated temperatures) and a proprietary knitted open tube design with minimal band-spreading to maintain analytical resolution from high-performance columns. Volume: descriptive number designates coil volume in µL; e.g., RXN 1000 coil has a volume of 1000 µL

• Coil: 0.018 inch ID polytetrafluoroethylene tubing knitted in a proprietary manner
• Fittings: 1/16” compression screws and ferrules made of PEEK
• Jacket: anodized aluminum tube and end-caps
• Maximum Operating Temperature: 120 °C
• Maximum Operating Pressure: 500 psi (3.4 MPa)
• Junction Tee: 316 Stainless Steel, 90° port, low-dead volume design which accepts 1/16” compression screw fittings

Price is for one coil assembly.
