Dionex BioLC AD25 Absorbance Detector with DX-LAN

The Dionex AD25 absorbance detector with DX-LAN, has a dual-beam with variable wavelength photometer, with an integrated holmium oxide filter for verification.

Specifications:

– Decibel level: 52 db

– Wavelength range: 190 nm to 800 nm variable; continuous in 1 nm steps

– Wavelength accuracy: ± 1 nm

– Bandwidth: <5 nm

– Autozero capability: 3 AU

– Autozero accuracy: ± 100 µAU

– Noise: ± 10 µAU peak-to-peak at 254 nm, 2-second rise time, flowing deionized water

– Drift: < 100 µAU/hour (after warm-up)

– Filter rise time: discrete settings of 0.1, 0.2, 0.5, 1.0, 2.0, 5.0, and 10.0 seconds

– Analog output range: discrete settings of 0.001, 0.005, 0.01, 0.05, 0.1, 0.5, 1.0, 2.0, and 3.0 AU

Specifications:

Flow accuracy: <1% of set value or ±2 µL/min, whichever is greater

Flow precision: <0.2%

Compositional accuracy: <±1%

Operating pressure: 35 MPa (5000 psi), maximum Low delay volume: <400 μL

Standard delay volume: <800 μL

** Other BioLC system components may be available at extra cost - please inquire directly for availability and pricing.

** SEE LINKS TO LITERATURE FOR MORE INFORMATION
