Fischer Porter VA Master FGM1190 Variable Area Flow Meter - 4.25US GPM

Fischer Porter VA Master FGM1190 Variable Area Flow Meter - 4.25US GPM

150

Available quantity: 2

orCall 1-514-464-6144

Description

The VA Master FGM1190 Flowrator meter is a glass tube variable-area flowmeter providing visual indication of flow rate over a 12-1/2 to 1 range on a linear scale. Seals in the meter can be either O-ring or packing gland type to suit the application. With either type of seal, the glass meter tube can be removed easily for range change or cleaning, without disassembling the end fittings or removing the meter from the line. Both types have the same external dimensions and are interchangeable with regard to piping assembly. Universal threaded process connections allow the meter to be installed with either horizontal or vertical piping arrangements. Screw-on flanges provide the maximum in versatility.

Price is for one flow meter.


** SEE LINK TO DATASHEET FOR MORE INFORMATION

Specifications

ManufacturerFischer Porter
ModelVA Master FGM1190
ConditionUsed
Serial NumberNone
MPN999A001U63
Condition DescriptionIN GOOD CONDITION - AS SEEN IN PHOTOS
Dimensions5"W x 5"D x 20"H
Weight (lbs)20
Country/region of manufactureUnited States
Custom LabelC3E
